Exclusive, world-class precision in a dual-array system
The Arias OptiMatrix™ 500 is the world's first transmitted light refractometer with precision comparable to high-end automatic reflected light refractometers.
This dual-array, automatic refractometer eliminates the need for shadowline intersect interpretation and delivers consistently repeatable results. The Arias OptiMatrix™ 500 compensates for temperature and delivers the results on an easy-to-read digital display.
| Catalog Number | 1310499SA (110v to 240v with US, EU, and UK power cords) |
| Operation | Semi-automatic, transmitted light laboratory refractometer |
| Automatic Reading Range | Shadowline within the field of view |
| Sample Types | Transparent and translucent liquids and solids |
| Illumination | 6 high intensity long life LEDs, 589nm |
| Reading Range | 1.30000 to 1.70000 Refractive Index and 0.00 to 95.00 % Brix (ICUMSA) |
| Reading Accuracy | +/- 0.00005 Refractive Index and +/- 0.03 % Brix |
| Calibration | Set point with distilled water and span point with NIST oils |
| Temperature Control Method | Ports for external circulator |
| Temperature Control Range | 10°C to 80°C |
| Temperature Precision | 0.01°C |
| Prism Assembly | Glass prism sealed with epoxy to 416 grade stainless steel housing |
| Display Graphic | LCD display, 44mm W x 44mm H (1.75" x 1.75") |
| User Interface | Simple, effective 5-button operation with on-screen instructions |
| Data Output | Two 9-pin RS232C serial ports |
| Baud Rate | User-definable up to 57,600 bps |
| Channels | Channel 1 is Brix (ICUMSA) and channel 2-15 is user defined (numerous scales available) |
| Calibration | History Record Maintains hundreds of the most recent calibration records |
| Automatic Temperature Equilibration Detection | Automatically detects temperature equilibrium point between the sample and the instrument |
| Password | Setup and menu parameters can be password protected |
| Languages | English, German, French, and Spanish |
| Net Weight | 7.84 kg (17.25 lb) |
| Warranty | 2 Years |
